Unveiling the ZKTeco Saturn Plus Series , an innovative swing barrier turnstile designed for an unparalleled passage experience. The Saturn Plus Series offers two models (S1000 Plus and S1200 Plus). Its chassis is made from cold-rolled steel SPCC (GB700), providing an IPX4 protection rating that ensures it can withstand water and dust. The Saturn Plus Series has been upgraded with a notable feature: the addition of six pairs of infrared sensors for dual pinch protection. It ensures enhanced safety and improved obstacle detection. Also, the authentication area is enhanced with 2.5D tempered glass for scratch resistance. Saturn Plus Series maintains its multi-authenticatian flexibility as before, with facial, QR code and RFID card verification. Additionally, the pedestal removal design makes it easier to installation.
Audio Indicator
Internal speaker
Visual Indicator
Saturn-S1000 Plus : Top LED indicator: Blue=Door closed/stand by
Green=Door opening Red=Door closing/alarm
Saturn-S1200 Plus : Side LED indicator Green=Lane available Red=Lane unavailable
Lane Type
Saturn-S1000 Plus : Single lane
Saturn-S1200 Plus : Dual Swing (for additional lane)
Lane Width (mm)
600mm (Standard)
Max 900mm (Optional)
Barrier Movement
Swing
Motor
DC brushless motor
Movement Speed
Average 1s per movement (Adjustable open/close timing)
Lid Material
Stainless steel & Polycarbonate
Lid Options Authentication Methods
Streamlined under mount options: QR Code / RFID
Surface mount option: Facial Authentication
Chassis Material
Cold-rolled steel SPCC (GB700) (Chassis Body) / Aluminum Alloy (Gate Column)
Chassis Colour
Sliver(standard), Gray(optional), Brown(optional)
Barrier Material
Light gray transparent acrylic(555*300mm)(standard)/Light gray transparent acrylic(555*375mm)(optional)
IR Sensors
6 pairs
Motherboard Function
System configuration, access control
Motherboard Communication
Fire alarm port (relay)*1, RS485 port*1,
Controller
Not equipped, allowing optional from C3/InBio Series or customization.
Credential Options
Under mount RFID reader: (support model: Pro ID Series, KR Series)
Under mount fingerprint reader: FR1200/FR1500S
Flow Rate
Facial Authentication: 15 passengers per minute
QR Code: 30 passengers per minute
RFID: 35 passengers per minute
Dimension (L*W*H)
1200 * 150 * 1020 mm
Emergency Mode
Support (swing barrier open automatically)
Ingress Protection Rating
IPX4
MCBF
3 million
MTTR
Less than 60 minutes
Packing Material
Carton(standard) / Wooden(optional)
Power Rating
10VA(Standby) 40VA(Operation)
Safety Features
Voltage free contact input for re alarm fail state
automatic swing barrier open during power off
Security Features
Anti-tailgating, anti-pinch
Supported Software
ZKBio CVSecurity
Certification
CE, FCC
