Wiegand Card Readers 125kHz EM or 13.56MHz IC card reader Wiegand interface
Read Range
KRxxx-E: Up to 10CM
KRxxx-M: Up to 5CM
Reading Time
≤ 300ms
Input Port
External LED Control
External Buzzer Control
Material
ABS + PC with texture
Output Format
KRxxx-E: 26bit Wiegand (Default)
KRxxx-M: 34bit Wiegand (Default)
Power Supply
DC 6-14V / Max.70mA
LED
Red and Green LEDs
Operating Temperature
-20°C to 65°C (-10° to +70°C)
Operating Humidity
10% to 90% relative humidity non-condensing
Ingress Protection Rating
KR600-E/M: IP65
KR601-E/M: IP65
KR602-E/M: IP64
(Silver and above members can download after logging in)
KR600
1.47MB
2023-05-23
